Underground Enclosures | Other Sumps

Select a category below

Octagonal

Rectangular

Vent Transition

Octagonal Sumps | 1.2m (48″) Octagonal Sump, Round Cover

Standard Internal Lid

S12SB-390

1.2m (48″) octagonal chamber, corbel, internal lid, adjustable skirt, frame and round 900mm (36″) composite cover.

Non-structural Lid

PDF Specs

CAD Drawings

Watertight Internal Platform

S12SB-390-WT

1.2m (48″) octagonal chamber, corbel, internal lid, adjustable skirt, frame and round 900mm (36″) composite cover.

Watertight Platform

PDF Specs

CAD Drawings

Rectangular Sumps | 1470mm (58″) x 990mm (39″) Solid Base Sump – S9

600mm (24″) Deep Sump

S9-3140

1470mm (58″) x 990mm (39″) x 600mm (24″) deep solid base sump, ideal for pipework transition.

PDF Specs

CAD Drawings

900mm (36″) Deep Sump

S9D-3140

1470mm (58″) x 990mm (39″) x 900mm (36″) deep solid base sump, ideal for pipework transition.

PDF Specs

CAD Drawings

Vent Transition Sumps

1100mm (43 3⁄8″) X 800mm (31 1⁄2″) Solid Base Sump

S11-2-VENT

PDF Specs

CAD Drawings

1500mm (59″) X 850mm (33″) Solid Base Sump

S100-2-VENT

PDF Specs

CAD Drawings
